Industrial | Type 76

Type 76

Type 76 (Type 76)

Product Description

The Type 70 buffer is a long stroke 700kN buffer available with 500mm and 600mm stroke. These are typically used on dockside cranes and in steel mills. The Type 70 buffers are also used on mining applications as they can be used vertically. They have also been used as end stops for funicular railways as they have the ability to be set at an angle.

Stroke 600 mm
Dynamic Capacity 336 kJ
Maximum End Force 700 kN
Static Start Force 12 kN
Static End Force 150 kN
