| Type 21/50

Type 21/50

Type 21/50 (Type 21)

Product Description

There are four different buffer units available for the Type 21 ranging from 50mm to 200mm.The Type 21 is a small unit with a lower capacity than other Oleo buffers so would generally be found on smaller cranes.These buffers are also used in steel mills as a stopper for hot slab works using multiple units.

Stroke 50 mm
Dynamic Capacity 10 kJ
Maximum End Force 250 kN
Static Start Force 3 kN
Static End Force 16 kN
