Industrial | Type 15

Type 15

Type 15 (Type 15)

Product Description

The Type 15 consists of two Type 9 stroke buffer capsules combined into one buffer assembly to provide a longer 800 mm stoke.

Typically used as end stops for either rail or heavy crane applications, on both dockside and offshore applictions.

The Type 24 buffer is a related unit consisting of two Type 23 buffer capsules and therefore is also more appropriate when needing to be fully compressed at low speeds.

Stroke 800 mm
Dynamic Capacity 476 kJ
Maximum End Force 700 kN
Static Start Force 1 kN
Static End Force 156 kN
